Hobbywing X6-SE 280KV Motor and 2270 Propeller Combo Kits-CCW
Hobbywing X6-SE 280KV Motor and 2270 Propeller Combo Kits-CCW - Image 2
Hobbywing X6-SE 280KV Motor and 2270 Propeller Combo Kits-CCW - Image 3

Hobbywing X6-SE 280KV Motor and 2270 Propeller Combo Kits-CCW

Specifications

  • Product Type: Integrated Drone Propulsion System
  • Motor KV: 280KV
  • Propeller: 2270 (CCW)
  • Motor Type: Brushless Motor
  • Application: UAV / Drone Systems

IBOTS's 10th Anniversary Sale

Hurry and get discounts on all Raspberry Products up to 20%

IBOTS1000

Price may vary for backorder items. Contact us for the latest price.

₹12,669.00

Available on backorder

Available on backorder

Add to compare
Add to wishlist
  • Pick up from the IBOTS Store

Free

  • Delivery Charges: Tamil Nadu

₹75 for parcels below 1 Kg and ₹100 for parcels weighing between 1 Kg to 2 Kg.

2-3 Days

₹75

  • Delivery Charges: Other South India

₹125 for parcels below 1 Kg and ₹175 for parcels weighing between 1 Kg to 2 Kg.

2-3 Days

₹125

  • Delivery Charges: North India

₹250 for parcels below 1 Kg and ₹325 for parcels weighing between 1 Kg to 2 Kg.

2-3 Days

₹250

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Rs. 99

  • Warranty 1 year

More details

  • Free Returns Policy

More details

Payment Methods:

1. Order the Product and Specify the Delivery Method

2. You Will Receive an Order Confirmation Message

3. Wait for Your Order to Arrive

4. Pick up Your Order at The Checkout Area

Description

The HOBBYWING X6-SE 280KV Motor with 2270 Propeller (CCW) is an integrated drone propulsion system designed for UAV applications. It combines a brushless motor with a compatible propeller to provide stable thrust and reliable operation. It is suitable for drone education, training, and professional applications where dependable propulsion and straightforward installation are important.

HOBBYWING X6-SE 280KV Motor with 2270 CCW Propeller

Features

  • Integrated drone propulsion system design.
  • 280KV brushless motor for UAV applications.
  • Compatible 2270 counter-clockwise (CCW) propeller.
  • Designed for stable and smooth flight performance.
  • Integrated components help simplify installation.
  • Durable construction for regular operation.
  • Suitable for drone training, education, and professional UAV projects.
  • Supports CAN digital and PWM analog control, as specified.

Specifications

Specification Details
Product Type Integrated Propulsion System
Motor KV 280KV
Motor Type Brushless Motor
Propeller 2270 CCW
Propeller Compatibility MFP 22 × 7.0 Carbon-Plastic Folding Propeller (as specified)
Battery Compatibility 6S LiPo
Recommended Battery 6S 30000mAh (as specified)
System Weight 373g including propellers (as specified)
Additional Weight Figure 300g (also listed in the supplied specifications; confirm what this refers to)
Dimensions 120 × 68 × 60mm (as specified)
Arm Compatibility 25mm tube diameter
ESC Rating 30A (60A peak, as specified)
Throttle Control CAN digital and PWM analog (as specified)
Communication Protocol CAN
Real-Time Monitoring RPM, throttle, current, voltage, and temperature (as specified)
Fault Storage ESC fault storage supported (as specified)
LED Indicator Intelligent status display (as specified)
Installation Integrated design
Frame Compatibility Quadcopter, hexacopter, and octocopter frames, subject to system compatibility
Flight Controller Support ArduPilot, VK, Byaero, and JIYI (as specified; verify compatibility)
Operating Features OTA updates and parameter tuning (as specified)
Recommended Takeoff Weight 8kg quadcopter (as specified)
Rated Thrust per Rotor 2kg (as specified)
Recommended Single-Axis Takeoff Weight 2–2.5kg (as specified; confirm the manufacturer’s terminology)
System Efficiency Up to 10g/W at 2.2kg thrust (as specified)
Typical Flight Time 45 minutes (as specified; depends on the complete aircraft setup)
Flight Time Claim Over 60 minutes per battery (also listed in the supplied specifications; verify test conditions)
Testing Standards DPV, vibration (0–600Hz/10G), thermal cycling, humidity, dust, and water ingress (as specified)
Service Life Testing 1000+ hours of laboratory testing (as specified)
Flight Verification 500 hours (as specified)

Applications

  • UAV and drone systems.
  • Drone education and training platforms.
  • Aerial photography and surveying drones.
  • Industrial inspection and mapping applications.
  • Compatible multirotor development and testing projects.

Package Includes

  • 1 × HOBBYWING X6-SE 280KV Motor
  • 1 × HOBBYWING 2270 Propeller (CCW)
  • 1 × Screw Pack

Important Note: Some supplied specifications list different system weights and flight times. Confirm these figures, the ESC rating, thrust data, and flight-controller compatibility against the official manufacturer datasheet before publishing or using them for aircraft design.
